ENER-J 150W Slimline DOB LED Street Light — 18,750 Lumens, 125 lm/W, Wide Voltage 175–400V, φ60 Pole Mount (F317)

At 150W and 18,750 lumens, the ENER-J F317 is built for the installations where output genuinely matters — wide municipal roads, major industrial estates, large logistics compounds, and high-priority infrastructure lighting. It’s a 150W LED street light for municipal roads and large-scale commercial applications that delivers serious, wide-area coverage at 125 lm/W efficiency — keeping energy consumption in check even at this output level, and performing reliably in the voltage conditions India’s grid actually delivers.

Why the F317 Is Built for Large-Scale, High-Priority Applications

• 18,750 lumens from 180 LEDs — wide-area coverage per fitting: At this lumen level, each F317 fitting covers a significantly wider road or compound area than lower-wattage streetlights — meaning fewer poles, fewer fittings, and a lower total installation cost for large projects, while maintaining the consistent illumination levels required for road safety and security compliance.
• φ60 pole-arm mounting — built for larger infrastructure poles: Unlike the φ50 arm of the 36W–100W models in the series, the F317 uses a φ60 pole-arm mount — the standard diameter for heavier-duty street lighting poles used on main roads and municipal infrastructure. An important practical detail for contractors and specifiers planning pole specifications.
• 125 lm/W efficiency at 150W — genuinely efficient at scale: Across a large installation of multiple F317 fittings, the 125 lm/W system efficiency translates to meaningful energy cost reduction compared to conventional 150W streetlights — without compromising on output. At municipal scale, the annual saving across hundreds of fittings is substantial.
• Wide 175–400V input — reliable across India’s infrastructure: Main roads and municipal installations often span areas with variable grid quality. The F317’s 175–400V wide-range input handles the full spectrum of Indian supply conditions — from low-voltage rural grid sections to high-voltage industrial supply — without fault, flicker, or LED degradation.
• DOB technology for long-life, low-maintenance operation: At 150W continuous operation, thermal management and component reliability are critical. By integrating the driver directly onto the LED board, the F317 eliminates the separate driver — the most common failure point in high-wattage conventional streetlights — resulting in better heat dissipation and significantly longer operational life between maintenance interventions.
• Built-in surge protection for infrastructure-grade reliability: Municipal and industrial power supplies are subject to significant switching events and transient voltage spikes. Built-in DOB surge protection handles these automatically — no external surge device, no additional installation cost, no maintenance requirement.
• Slimline die-cast aluminium housing at 471 × 155 × 22mm: Despite driving 180 LEDs at 150W, the F317 maintains a slim, aerodynamic profile. Die-cast aluminium construction provides the thermal conductivity and structural rigidity needed for permanent pole mounting in exposed outdoor environments.
• PF > 0.9 and CRI > 80 for compliant, high-quality output: High power factor for grid-efficient operation across large installations. CRI above 80 for accurate colour rendering — vehicles, road markings, pedestrians, and hazards all clearly visible under natural-looking light.

Ideal Applications

• Wide municipal roads and arterial streets
• Major industrial estate and factory perimeter roads
• Large logistics yards and freight compound lighting
• Port, airport, and infrastructure perimeter lighting
• Large open-air parking areas and transport hubs
• Highway service areas and toll plaza lighting

Specifications

• SKU: F317
• Power: 150W
• Lumen Output: ~18,750 Lumens
• System Efficiency: 125 lm/W
• LED Count: 180 LEDs
• Technology: DOB (Driver-on-Board)
• Input Voltage: AC 175–400V (Wide Range)
• Power Factor: PF > 0.9
• CRI: RA > 80
• Reflector: High-Efficiency Nano Reflector
• Housing: Die-Cast Aluminium, Grey
• Housing Size: 471 × 155 × 22mm (φ60)
• Mounting: Standard Pole-Arm Mount (φ60)
• Surge Protection: Built-in (via DOB design)
• Power Output: 100% Rated Power

What’s in the Box

• 1 × ENER-J F317 150W Slimline DOB LED Street Light
• 1 × Mounting Hardware
• 1 × User Manual

For wide roads, large compounds, and large-scale infrastructure where consistent, professional-grade output is required from every single fitting — the F317 is the specification. Built to perform, built to last. Order yours today.
